This is our low profile, flat type power relay V6. It is available in 1 Form A contact only. It has 200mW high sensitivity coil power. But when coil voltage reached 48VDC, the coil power is 250mW. The Tungsten lamp load is 10A 125VAC. V6 has passed UL E164730, UL E322395, CSA 1460119, TUV 50116138-0001, TUV 50116138-0002, CQC 08002027612 safety approvals.
| Contact Data | |
| Contact Form | 1A |
| Contact Rating | 15A 125VAC 10A 250VAC/24VDC |
| Max.Switching Voltage | 250VAC/30VDC |
| Max.Switching Current | 16A |
| Max.Switching Power | 4,000VA,480W |
| Min.Switching Load | 5VDC,100mA |
| Coil Data | |
| Coil Voltage | 3～48VDC |
| Coil Power | 200mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 750VAC,1min |
| Coil and Contacts | 2,500VAC,1min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +85℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 25pcs/Tube |
| Qty/Ctn (Pcs) | 1000/Carton |
| Carton Size L×W×H(mm) | 647×235×136 |
| Approx N.W. | 8.6 |
| Approx G.W. | 10.0 |
Applications: The sound field.
