This product HRS1 is a long-history signal relay in our company. In 1991, we developed and produced HRS1 and begin to export through foreign trade companies. It is available in 1 Form C contact only. It has two contact rating: 1A and 3A. It has two coil sensitivity: high sensitivity (200mW) and standard (360mW). Also, it passed UL E164730, TUV 50103498 and CQC 12002086133 safety standards.
| Contact Data | |
| Contact Form | 1C |
| Contact Rating | 1A 120VAC/24VDC 3A 120VAC/24VDC |
| Max.Switching Voltage | 220VAC/30VDC |
| Max.Switching Current | 3A |
| Max.Switching Power | 360VA,72W |
| Min.Switching Load | 5VDC,10mA |
| Coil Data | |
| Coil Voltage | 3～24VDC |
| Coil Power | 200mW 360mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 750VAC,1min |
| Coil and Contacts | 1,000VAC,1min | |
| Electrical Life(ops.) | 100,000(1A 120VAC/24VDC) 50,000(3A 120VAC/24VDC) |
|
| Operating Temperature | -25℃ to +70℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 25pcs/Tube |
| Qty/Ctn (Pcs) | 2000/Carton |
| Carton Size L×W×H(mm) | 466×306×140 |
| Approx N.W. | 6.8 |
| Approx G.W. | 9.1 |
Applications: The sound field.
Frequently asked questions:
Q1. How about your company? Do you have factories?
A: Our HKE company is one of the biggest relay manufacturers in China. Our products cover almost all the automotive market in China and have a good reputation. Of course we have our own factories, so our products come directly from the production line.
Q2. Can you send samples?
A: Yes, we can send you samples. More requirements you can contact us by email.
Q3. How long is your lead time?
A: Because of influence of COVID 19, generally the time is over 30 days. The demand for some popular products exceeds the supply, so the lead time maybe longer. But we will arrange our production as soon as possible according to your order.
Q4. How about your after-sales service?
A: We provide perfect after-sales service. If you have any problems of products, you can consult us by email. We will give you best solutions as soon as possible.
