HRS1KH3 is our HKE microminiature power relay. In 1996 we successfully created HRS1KH3 power relay. It can produce a jump in one or more electrical output circuits, and can be used in a neutral point directly grounded system as a directional element for zero-sequence current protection. It has Ag Alloy contact material. This product is available in 1 Form A contact only and the coil power is 200mW. It has UL E164730, CSA 1426410, CQC 12002086133 safety approvals.
| Contact Data | |
| Contact Form | 1A |
| Contact Rating | 3A 220VAC/30VDC |
| Max.Switching Voltage | 220VAC/30VDC |
| Max.Switching Current | 3A |
| Max.Switching Power | 660VA,90W |
| Min.Switching Load | 5VDC,100mA |
| Coil Data | |
| Coil Voltage | 3～24VDC |
| Coil Power | 200mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 750VAC,1min |
| Coil and Contacts | 1,000VAC,1min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -25℃ to +70℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 25pcs/Tube |
| Qty/Ctn (Pcs) | 2000/Carton |
| Carton Size L×W×H(mm) | 466×306×140 |
| Approx N.W. | 7.0 |
| Approx G.W. | 9.1 |
Applications: The sound field.
