This is HKE microminiature power relay HRS3F. It has 5A switching capacity and two kinds of coil sensitivity: high sensitivity (200mW) and standard (450mW). The contact form is 1 Form A. It is used plastic sealed type to pack. HRS3F has reinforced insulation between coil and contact. Its safety approvals are TUV 50223752, CQC 12002076143, UL E164730, Explosion-proof Certificate CNEx16.3129U.
| Contact Data | |
| Contact Form | 1A |
| Contact Rating | Resistive: 5A 250VAC/30VDC Horsepower: 1/3HP 240VAC(450mW) |
| Max.Switching Voltage | 277VAC/30VDC |
| Max.Switching Current | 5A |
| Max.Switching Power | 1,250VA,150W |
| Min.Switching Load | 5VDC,100mA |
| Coil Data | |
| Coil Voltage | 5～24VDC |
| Coil Power | 200mW 450mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 1,000VAC,1min |
| Coil and Contacts | 4,000VAC,1min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +85℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 100pcs/Box(paper) |
| Qty/Ctn (Pcs) | 1000/Carton |
| Carton Size L×W×H(mm) | 284×250×180 |
| Approx N.W. | 5.9 |
| Approx G.W. | 6.9 |
Applications: The sound field.
