This is our microminiature power relay HRS3. It has two kinds of coil sensitivity: high sensitivity (200mW) and standard (450mW). The Max. Switching current is 10A. It is available in 1 Form A and 1 Form C contact. HRS3 has UL E164730, UL E322395, CSA 1063016 (LR 109368), Explosion-proof Certificate CNEx16.3130U safety standards.
| Contact Data | |
| Contact Form | 1A, 1C |
| Contact Rating | A: 10A 125VAC, 5A 250VAC/28VDC C: NO/NC: 5A/3A 250VAC/28VDC |
| Max.Switching Voltage | 250VAC/28VDC |
| Max.Switching Current | 10A |
| Max.Switching Power | 1,250VA, 280W |
| Min.Switching Load | 5VDC, 100mA |
| Coil Data | |
| Coil Voltage | 3～24VDC |
| Coil Power | 200mW 450mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 1,000VAC, 1min |
| Coil and Contacts | A: 3,500VAC, 1 min C: 2,500VAC, 1 min |
|
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +85℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 100pcs/Box(paper) |
| Qty/Ctn (Pcs) | 1000/Carton |
| Carton Size L×W×H(mm) | 284×250×180 |
| Approx N.W. | 5.9 |
| Approx G.W. | 6.7 |
Applications: The sound field.
