NO.CQC09002035018
NO.1063015(LR 106040)
NO.50134947
NO.E164730
The product HRM1 is our general purpose power relay. It is available in 2 Form A contact and 2 Form C contact. It has two kinds of coil sensitivity: high sensitivity (540mW) and standard (720mW). It has 4000V dielectric strength between coil and contacts. It has a slim type and the creepage distance is 8mm. HRM1 has passed UL E164730, CSA 1063015 (LR 106040), TUV 50134947-001, CQC 9002035018 safety standards.
| Contact Data | |
| Contact Form | 2A,2C |
| Contact Rating | Resistive: 5A 250VAC/24VDC TV Rating: TV-5 Inductive: 5A 250VAC/24VDC(COSΦ=0.4, L/R=7ms) |
| Max.Switching Voltage | 250VAC/30VDC |
| Max.Switching Current | 5A |
| Max.Switching Power | 1,250VA,150W |
| Min.Switching Load | 5VDC,100mA |
| Coil Data | |
| Coil Voltage | 3～48VDC |
| Coil Power | 540mW 720mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 1,000VAC,1min |
| Coil and Contacts | 4,000VAC,1min | |
| Electrical Life(ops.) | 100,000 20,000(COSΦ=0.4, L/R=7ms) |
|
| Operating Temperature | -30～+55℃(720mW) -30～+70℃(540mW) |
|
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 100pcs/Box(foam) |
| Qty/Ctn (Pcs) | 1000/Carton |
| Carton Size L×W×H(mm) | 444×378×255 |
| Approx N.W. | 13 |
| Approx G.W. | 14.8 |
Applications: The sound field.
Frequently asked questions:
Q1. How about your company? Do you have factories?
A: Our HKE company is one of the biggest relay manufacturers in China. Our products cover almost all the automotive market in China and have a good reputation. Of course we have our own factories, so our products come directly from the production line.
Q2. Can you send samples?
A: Yes, we can send you samples. More requirements you can contact us by email.
Q3. How long is your lead time?
A: Because of influence of COVID 19, generally the time is over 30 days. The demand for some popular products exceeds the supply, so the lead time maybe longer. But we will arrange our production as soon as possible according to your order.
Q4. How about your after-sales service?
A: We provide perfect after-sales service. If you have any problems of products, you can consult us by email. We will give you best solutions as soon as possible.
