Product Model: HEV50
150A of switching capability
Contact: 1 Form A
With arc extinguishing device, increased load capacity
Optional resistor or diode to protect the coil circuit
75℃ of working temperature
According to customer needs to select connector
Friendly product (RoHS Compliant)
This is HV direct current relay HEV50. It is available in 1 Form A contact. Specially, it can carry with extinguishing device to increase the load capacity. It has parallel resistor or diode to protect the coil circuit. Customers can select connector with their needs. The Max. Switching capacity is 150A.
Product Parameters：| Contact Data | |
| Contact Form | 1A |
| Contact Rating | 150A |
| Max.Switching Voltage | 110VDC |
| Max.Switching Current | 150A |
| Max.Switching Power | 1800W |
| Min.Switching Load | |
| Coil Data | |
| Coil Voltage | DC12V， DC24V，DC36V,DC48V |
| Coil Power | 2.4W 2.6W |
| General Data | ||
| Dielectric Strength | Open Contacts | 550VAC |
| Coil and Contacts | 550VAC | |
| Electrical Life(ops.) | Resistance：12VDC 150A 50000ops ON/OFF:1S/4S
24VDC 100A 50000ops ON/OFF:1S/4S 36VDC 70A 50000ops ON/OFF:1S/4S 48VDC 60A 50000ops ON/OFF:1S/4S 72VDC 50A 50000ops ON/OFF:1S/4S 110VDC 30A 50000ops ON/OFF:1S/4S |
|
| Operating Temperature | -40℃ to +75℃ | |
| Terminal Type | Screw | |
