NO.CQC08002027615
NO.50125641
NO.E164730
NO.40009646
This is our power relay CMP7. It is available in both open type and plastic sealed package. It has two kinds of contact form: 1 Form A and 1 Form C. It owns many kinds of contact ratings. The high contact capacity can up to 40A 250VAC. CMP7 has passed UL E164730, CQC 08002027615, VDE 40009646, TUV 50125641-0001, TUV 50125641-0002 safety standards.
| Contact Data | |
| Contact Form | 1A,1C |
| Contact Rating | A :30A 250VAC/24VDC AT : 40A 250VAC/24VDC C:NO:20A |
| Max.Switching Voltage | 250VAC/28VDC |
| Max.Switching Current | 30A 40A(T) |
| Max.Switching Power | 7,500VA,560W |
| Min.Switching Load | 5VDC,100mA |
| Coil Data | |
| Coil Voltage | 5～48VDC |
| Coil Power | 900mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 1,500VAC,1min |
| Coil and Contacts | 2,500VAC,1min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +85℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 25pcs/Box(foam)(plastic Sealed Type) 40pcs/Box(plastic) |
| Qty/Ctn (Pcs) | 500/Carton(plastic Sealed Type) 400/Carton(Open Type) |
| Carton Size L×W×H(mm) | 450×339×201(plastic Sealed Type) 400×280×185 |
| Approx N.W. | 12.0(plastic Sealed Type) 4.0(Open Type) |
| Approx G.W. | 13.5(plastic Sealed Type) 5.0(Open Type) |
Applications: It is widely used in flash light, control instruments, window motor control, low temperature start, electronic positioning instruments, center door lock, motor control, etc.
Frequently asked questions:
Q1. How about your company? Do you have factories?
A: Our HKE company is one of the biggest relay manufacturers in China. Our products cover almost all the automotive market in China and have a good reputation. Of course we have our own factories, so our products come directly from the production line.
Q2. Can you send samples?
A: Yes, we can send you samples. More requirements you can contact us by email.
Q3. How long is your lead time?
A: Because of influence of COVID 19, generally the time is over 30 days. The demand for some popular products exceeds the supply, so the lead time maybe longer. But we will arrange our production as soon as possible according to your order.
Q4. How about your after-sales service?
A: We provide perfect after-sales service. If you have any problems of products, you can consult us by email. We will give you best solutions as soon as possible.
