This is automotive mute relay CMA59. The sound pressure of this relay is less than or equal to 50dB. It is available in 1 Form A contact and 1 Form C contact. The Max. Switching capacity is 30A. It can carry with parallel resistor (12V-680Ω). It is used quick-flat connection terminal. CMA59 compliance to RoHS and ELV.
| Contact Data | |
| Contact Form | 1A,1C |
| Contact Rating | A(Resistive)：20A 14VDC C(Resistive)：NO:20A 14VDC NC:10A 14VDCMotor: 25A(peak) 14VDC |
| Max.Switching Voltage | 16VDC |
| Max.Switching Current | 30A |
| Max.Switching Power | 480W |
| Min.Switching Load | 1A 6VDC |
| Coil Data | |
| Coil Voltage | 12VDC |
| Coil Power | 0.64W 0.85W |
| General Data | ||
| Dielectric Strength | Open Contacts | 550VAC,50/60Hz,1 min |
| Coil and Contacts | 550VAC,50/60Hz,1 min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +125℃ | |
| Terminal Type | Quick connect | |
| Packaging | ||
| Packing Method | 100pcs/Box(plastic) | |
| Qty/Ctn (Pcs) | 1000/Carton | |
| Carton Size L×W×H(mm) | 396×322×268 | |
| Approx N.W. | 11.6 | |
| Approx G.W. | 13.5 | |
Applications: It is used in some car silencing devices
