Products
The product CMA57 is our microminiature automotive relay. It is available in 1 Form A contact only. It is used in 2.8mm flat quick connection terminal. It can parallel with 1000Ω resistor or with none (standard). It can work in a 125℃ ambient temperature. CMA57 complies to RoHS, ELV directive.
| Contact Data | |
| Contact Form | 1A |
| Contact Rating | 20A 14VDC |
| Max.Switching Voltage | 16VDC |
| Max.Switching Current | Make:100A Break:30A |
| Max.Switching Power | 320W |
| Min.Switching Load | 6VDC 1A |
| Coil Data | |
| Coil Voltage | 12VDC |
| Coil Power | 0.95W 1.1W |
| General Data | ||
| Dielectric Strength | Open Contacts | 550VAC,50/60Hz,1 min |
| Coil and Contacts | 550VAC,50/60Hz,1 min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +125℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 100pcs/Box(plastic) |
| Qty/Ctn (Pcs) | 1000/Carton |
| Carton Size L×W×H(mm) | 369×334×263 |
| Approx N.W. | 10.0 |
| Approx G.W. | 12.6 |
Applications: Center door lock, Mirror adjusting, Turn signal, Automatic doors and windows, Seat adjustment, Speed limit signal control, Preheating control, Wiper control
