This is microminiature automotive relay CMA55. It has double N.O. contact. The nominal coil power is 1.0W and Max. Switching current is 2×10A.
| Contact Data | |
| Contact Form | 2A |
| Contact Rating | 2 × 6A 13.5VDC Resistive |
| Max.Switching Voltage | 14VDC |
| Max.Switching Current | 2×10A |
| Max.Switching Power | 2×81W |
| Min.Switching Load | 6VDC 1A |
| Coil Data | |
| Coil Voltage | 6～24VDC |
| Coil Power | 1.0W |
| General Data | ||
| Dielectric Strength | Open Contacts | 550VAC,1min |
| Coil and Contacts | 550VAC,1min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +85℃ | |
| Terminal Type | PCB | |
| Packaging | |
| Packing Method | 25pcs/Tube |
| Qty/Ctn (Pcs) | 1000/Carton |
| Carton Size L×W×H(mm) | 371×229×146 |
| Approx N.W. | 5.7 |
| Approx G.W. | 6.8 |
Applications: car alarm, reverse sensor, etc
