This is our microminiature automotive relay CMA34. It is available in plastic sealed type or bayonet type. There are two kinds of contact form, 1 Form A and 1 Form C. It is used 2.8mm flat quick connection terminal. It ensures compliance to RoHS, ELV Directive. The Max. Switching current is 150A (Make NO) or 35A (Break NO).
| Contact Data | |
| Contact Form | 1A, 1C |
| Contact Rating | NO/NC:35A/20A 14VDC NO/NC:20A/10A 28VDC |
| Max.Switching Voltage | 40VDC |
| Max.Switching Current | Make:150A Break:35A |
| Max.Switching Power | 490W(12V),560W(24V) |
| Min.Switching Load | – |
| Coil Data | |
| Coil Voltage | 12V, 24V |
| Coil Power | Nominal Coil Power: 12V: 1200mW 24V: 1400mW |
| General Data | ||
| Dielectric Strength | Open Contacts | 550VAC,50/60Hz,1 min |
| Coil and Contacts | 550VAC,50/60Hz,1 min | |
| Electrical Life(ops.) | 100,000 | |
| Operating Temperature | -40℃ to +125℃ | |
| Terminal Type | Quick connect | |
| Packaging | |
| Packing Method | 50pcs/Box(plastic) |
| Qty/Ctn (Pcs) | 500pcs/Carton |
| Carton Size L×W×H(mm) | 444×269×182 |
| Approx N.W. | 9.5 |
| Approx G.W. | 10.3 |
Applications: Heater (seat, front/rear window heating control), Fan control, Horn control, Start-stop control, Solenoid control, Fog light/headlamp control, Automobile air condition, Oil Pump, Lifting device, Interlock device
Frequently asked questions:
Q1. How about your company? Do you have factories?
A: Our HKE company is one of the biggest relay manufacturers in China. Our products cover almost all the automotive market in China and have a good reputation. Of course we have our own factories, so our products come directly from the production line.
Q2. Can you send samples?
A: Yes, we can send you samples. More requirements you can contact us by email.
Q3. How long is your lead time?
A: Because of influence of COVID 19, generally the time is over 30 days. The demand for some popular products exceeds the supply, so the lead time maybe longer. But we will arrange our production as soon as possible according to your order.
Q4. How about your after-sales service?
A: We provide perfect after-sales service. If you have any problems of products, you can consult us by email. We will give you best solutions as soon as possible.
